Application Range

Suitable for packaging various types of powder materials, including:

Package Types: Back Seal Stick Bags (Sample materials: Protein powder, coffee, herbal extract, etc.)

Sample Materials & Finished Stick Packs Showcase:

Protein Powder

Coffee Powder

Herbal Extract

Stick Pack Samples

See our high-speed multi-lane packing machine operating live in action.

GMP Standard Compliance: The entire machine is constructed from food-grade 304 stainless steel, fully meeting GMP production standards.
Stable Bag Formation: Equipped with an automatic film offset correction system to ensure precise and stable bag alignment.
Aesthetic Sealing: Servo motor film pulling ensures more stable sealing and cleaner, high-quality finished stick packs.
Multilingual Touchscreen: Intuitive touch screen operation defaults to Chinese and English; customized languages are available upon request.
Automated Safety Alarms: Features automatic film breakage recognition, auto alarm, automatic shutdown, and a roll film alignment/docking mechanism.
High Efficiency & Smart Control: Built with top-tier brand electrical components and a intelligent PLC control system, offering high automation, rapid speed, and top performance.

Model	CY300BF	CY600BF	CY900BF
Lanes	2-4 Lanes	3-10 Lanes	4-16 Lanes
Bag Width	20-70 mm	20-95 mm	20-105 mm
Max Film Width	300 mm	600 mm	900 mm
Sealing Type	Back Seal / Stick Pack
Packing Speed	20 - 40 Bags / Lane / Min
Dosing Method	Long Screw / Short Screw / Short Screw with Measuring Cup
Cutting Type	Straight Cutting / Zig-Zag Cutting / Round Cutting / Die-Cut
Bag Length	50 mm - 180 mm
Power Supply	50Hz / 220V / 3.5kW	50Hz / 220V / 5.5kW	50Hz / 220V / 7.5kW
Dimensions (mm)	1900 * 1440 * 3130	1860 * 1750 * 3200	1860 * 2050 * 3300
Machine Weight	Approx. 900 kg	Approx. 1200 kg	Approx. 1500 kg
