Automate your powder and granular packaging line with precise weighing and dust-free operations. Specifically designed for 10kg - 50kg valve bags.
Ultra-High Precision: ±0.2% accuracy powered by METTLER TOLEDO load cells.
Maximum Output: Up to 400 - 600 bags per hour per spout.
Dust-Free Technology: Enclosed filling nozzle with negative pressure return.
Global Components: Siemens PLC, Schneider electrics, and AirTAC pneumatics.
ONLINE MESSAGELeave your requirements below for a quick quote!
Extraction Rate
Countries Exported
Quality Warranty
Technical Support
A completely automated workflow reducing labor and ensuring highly consistent bag weights.
Operator or Auto-Placer inserts the empty valve bag onto the filling spout. System locks it securely.
Variable frequency impeller or pneumatic air blows material into the bag with fast/slow dual modes.
Integrated load cells tare automatically and stop material flow instantly when target weight is hit.
Bag is automatically pushed off onto a belt conveyor. Optional ultrasonic sealing for 100% leak proofing.
Choose the right feeding technology based on your material's bulk density and flowability.
Best for high-density, fine powders like cement, dry mortar, and gypsum.
Feeding type: Motorized Impeller
Speed: 400-600 bags/hour
Feature: High-speed forcing feed
Ideal for granular or fluidic powders like chemicals, resins, and food ingredients.
Feeding type: Compressed Air
Speed: 200-400 bags/hour
Feature: No material breakage/friction
Upgrade to a fully automated line by replacing manual bag hanging with a robotic arm.
Empty bag magazine capacity: 200 bags
Compatibility: Fits all our fillers
Feature: Vacuum suction pad mechanics
Standard parameters for our Valve Bag Packaging Machines.
| Specification | Impeller Type | Pneumatic Type |
|---|---|---|
| Weighing Range | 10kg - 50kg | 10kg - 50kg |
| Packing Speed (Per Spout) | 400 - 600 Bags / Hour | 200 - 400 Bags / Hour |
| Weighing Accuracy | ±0.2% - 0.4% | ±0.2% - 0.4% |
| Air Supply Request | 0.4 - 0.6 MPa | 0.6 - 0.8 MPa |
| Power Supply | 380V, 50Hz, 3 Phase (Customizable) | 380V, 50Hz, 3 Phase (Customizable) |
| Core Controls | Siemens PLC + Touch Screen + METTLER TOLEDO Load Cells | |
Strict quality control from raw steel cutting to final machine assembly and testing.
Delivering robust engineering and peace-of-mind service to worldwide customers.
From factory layout design to installation and training, we handle the entire project.
All product contact parts can be made of SS304/SS316L for chemical/food safety.
Independent R&D in dust collection and weighing logic ensures top-tier performance.
Over 10,000 successful packaging lines operating reliably across 30+ countries.
Output increased to 1,600 bags/hour.
Dust reduction by 95%, passing local environmental checks.
Weighing accuracy stabilized at ±50g per 25kg bag.
We are a leading manufacturer specializing in industrial packaging and palletizing automation.
With over two decades of engineering expertise, we provide high-quality bagging machines for powders and granules. Our equipment utilizes global premium brands for core components to ensure long service life and easy maintenance. From single bagging stations to fully robotic palletizing lines, we empower factories to achieve higher efficiency with lower labor costs.
